Physical Properties |
Value |
Unit |
Test Method |
|
Hardness (5 sec) |
95 |
Shore A |
ASTM D2240 |
|
Specific Gravity |
1.24 |
|
ASTM D792 |
|
Tensile Strength |
2000 (13.7) |
psi (MPa) |
ASTM D412 |
|
Ultimate Elongation |
360 |
% |
“ |
|
Tensile Stress at |
|
|
|
|
- 100 % Elongation |
1400 (9.6) |
psi (MPa) |
ASTM D412 |
|
- 300 % Elongation |
1800 (12.4) |
psi (MPa) |
“ |
|
Tear Strength |
|
|
|
|
Graves |
340 (6) |
lb/in (kg/mm) |
ASTM D624 (die C) |
|
Trouser |
90 (1.6) |
lb/in (kg/mm) |
ASTM D470 |
|
Taber Loss (1000 rev) |
0.0106 (300) |
oz (mg) |
ASTM D3389 (H18, 1000g) |
|
Tm (by DSC) |
350 (175) |
°F (°C) |
C& J Advanced Materials |
|
Tg (by DSC) |
-34 (-30) |
°F (°C) |
C& J Advanced Materials |
Recommended Starting Extrusion Temperature Profile:
|
|
°F/°C |
|
Zone 1 |
320/160 |
|
Zone 2 |
330/165 |
|
Zone 3 |
340/170 |
|
Zone 4 |
350/175 |
|
Adapter (5) |
360/180 |
|
Die Zone 1 (6) |
360/180 |
|
Die Zone 2 |
360/180 |
Noveon® ZHF95AT3 TPU zero halogen flame retardant TPU for high flame performance cable jacket
|
Application Properties |
Value |
Unit |
Test Method |
|
Limiting Oxygen Index |
38 |
N/A |
ASTM D2863 |
|
UL 94 Vertical Flame Test, 75 mils (1.9 mm) |
V-0 |
N/A |
ASTM D3801 |
|
Surface Resistivity |
5.6 x 1014 |
Ω/sq |
ASTM D257 |
|
Volume Resistivity |
5.6 x 1012 |
Ω.cm |
ASTM D257 |
|
Insulation Resistance |
2.9 x 1010 |
Ω |
ASTM A717 |
|
Dissipation Factor @ 1 kHz @ 1 MHz |
0.04 0.05 |
|
ASTM D2520 |
|
Dielectric Constant @ 1 kHz @ 1 MHz |
4.5 5.7 |
|
ASTM D2520 |
|
Ross Flex |
No Cut Growth |
|
ASTM D257 |
|
Air Oven, 7 days, 113°C Strength Retention Elongation Retention |
85 90 |
% |
ASTM D412 |
|
Air Oven, 7 days, 121°C Strength Retention Elongation Retention |
75 90 |
% |
ASTM D412 |
|
IRM 902 Oil, 7 Days, 100°C Strength Retention Elongation Retention |
100 80 |
% |
ASTM D412 |
