Test samples were annealed at 100°C and 24 hours at room temperature before testing.

**These are typical values and should not be used for specifications.



June 4, 2007



The information contained herein is believed to be reliable, but no representations, guarantees or warranties of any kind are made as to its accuracy, suitability for particular applications or the results to be obtained. The information is based on laboratory work with small-scale equipment and does not necessarily indicate end product performance. Because of the variations in methods, conditions and equipment used commercially in processing these materials, no warranties or guarantees are made as to the suitability of the products for the applications disclosed. Full-scale testing and end product performance are the responsibility of the user. Lubrizol Advanced Materials, Inc. shall not be liable for and the customer assumes all risk and liability of any use or handling of any material beyond Lubrizol Advanced Materials, Inc.'s direct control. The SELLER MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES



OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Nothing contained herein is to be considered as permission, recommendation, nor as an inducement to practice any patented invention without permission of the patent owner.



Injection Molding Guide Test Machine


Manufacturer: Engel (Model: ES240/75P)


Clamping Force: 75 ton


Screw Diameter: 35mm


Screw Stroke: 160mm


Lubrizol Chemicals Mold No.: M-34


Cavity Dimension: 125*125*2.0 mm



Drying Conditions


Estane® Skythane™ T465A TPU

Drying	Conditions
Recommend 1	70~80°C for 4-5 hours by dehumidifying dryer

Injection Conditions

Barrel Temperature
Feeding Zone	165~180
Metering Zone	170~185
Nozzle	175~190
Injection Conditions (I)
Injection Pressure (psi)	1200~2000
Injection Speed	Slow
Hold Pressure (psi)	800~1400
Injection Time(s)	15~20
